26. Capacitors & Dielectrics

What is the equivalent capacitance of a $4.0\mathrm{\mu }\mathrm{F}$ capacitor and $6.0\mathrm{\mu }\mathrm{F}$ capacitor connected in series?

What is the equivalent capacitance of a $4.0\mathrm{\mu }\mathrm{F}$ capacitor and $6.0\mathrm{\mu }\mathrm{F}$ capacitor connected in parallel?

In Fig. E24.20

, C1 = 6.00 uF, C2 = 3.00 uF, and C3 = 5.00 uF. The capacitor network is connected to an applied potential Vab. After the charges on the capacitors have reached their final values, the charge on C2 is 30.0 mC. (a) What are the charges on capacitors C1 and C3? (b) What is the applied voltage Vab?

For the system of capacitors shown in Fig. E24.16

, find the equivalent capacitance (a) between b and c.

Figure E24.14

shows a system of four capacitors, where the potential difference across ab is 50.0 V. (c) How much charge is stored in each of the 10.0-uF and the 9.0-uF capacitors?

Figure E24.14

shows a system of four capacitors, where the potential difference across ab is 50.0 V. (b) How much charge is stored by this combination of capacitors?
